pygmt.Figure.subplot

Figure.subplot(nrows=1, ncols=1, autotag=False, tag_position=None, tag_box=None, tag_orientation=None, tag_number_style=None, tag_font=None, autolabel=False, margins=None, title=None, projection=None, frame=False, region=None, verbose=False, **kwargs)

Manage figure subplot configuration and selection.

This method is used to split the current figure into a rectangular layout of subplots that each may contain a single self-contained figure. Begin by defining the layout of the entire multi-panel illustration. Several parameters are available to specify the systematic layout, labeling, dimensions, and more for the subplots.

Full GMT docs at https://docs.generic-mapping-tools.org/6.6/subplot.html#synopsis-begin-mode.

Aliases:

C = clearance Ff = figsize Fs = subsize SC = sharex

SR = sharey B = frame J = projection M = margins

R = region T = title V = verbose

Parameters:

• nrows (int, default: 1) – Number of vertical rows of the subplot grid.

• ncols (int, default: 1) – Number of horizontal columns of the subplot grid.

• figsize (list) – Specify the final figure dimensions as [width, height].

• subsize (list) – Specify the dimensions of each subplot directly as [width, height]. Note that only one of figsize or subsize can be provided at once.

• autotag (str | bool, default: False) –

  Specify automatic tagging of each subplot. It can accept a number, or a letter. The number or letter can be surrounded by parentheses on any side if these should be typeset as part of the tag. This sets the tag of the first, top-left subplot and others follow sequentially. If set to True, default to "a)".

  Examples are:

  • autotag="a": tags are a, b, c, …

  • autotag="1": tags are 1, 2, 3, …

  • autotag="a)": tags are a), b), c), …

  • autotag="(c)": tags are (c), (d), (e), …

  • autotag=True: same as autotag="a)".

• tag_position (Literal['TL', 'TC', 'TR', 'ML', 'MC', 'MR', 'BL', 'BC', 'BR'] | Position | None, default: None) –

  Position of the subplot tag on the plot. It can be specified in two ways:

  • A 2-character justification code for a position inside the plot, e.g., "TL" for Top Left corner inside the plot.

  • A pygmt.params.Position object to fully control the position and offset. Note: the refpoint propterty of the Position object must be an two-character justification code, and cstype must be set to either "inside" or "outside",

  If not specified, defaults to Top Left corner inside the plot with the offset default to ("4p", "4p"), i.e., 20% of the FONT_TAG size.

• tag_box (Box | None, default: None) –

  Draw a box around the subplot tag. See pygmt.params.Box for details on how to specify the box.

  Notes on the use of the ``Box`` class:

  • The property clearance only accept one or two values.

  • The property inner_pen/inner_gap/radius is not supported.

• tag_number_style (Literal['arabic', 'roman', 'Roman'] | None, default: None) –

  Style of the subplot tag numbers. It can be:

  • "arabic": Arabic numerals: 1, 2, 3, … [Default].

  • "roman": Lowercase Roman numerals: i, ii, iii, …

  • "Roman": Uppercase Roman numerals: I, II, III, …

• tag_orientation (Literal['horizontal', 'vertical'] | None, default: None) –

  Orientation of the subplot tag. It can be:

  • "horizontal": Increase tag numbers horizontally across rows [Default].

  • "vertical": Increase tag numbers vertically down columns.

• tag_font (str | None, default: None) – Font for the subplot tag [Default to "20p,Helvetica,black"].

• autolabel (str | bool, default: False) –

  Specify automatic tagging of each subplot.

  Deprecated since version v0.19.0: Use the parameters autotag, tag_position, tag_box, tag_number_style, tag_orientation, and tag_font instead.

• clearance (str or list) – [side]clearance. Reserve a space of dimension clearance between the margin and the subplot on the specified side, using side values from w, e, s, or n; or x for both w and e; or y for both s and n. No side means all sides (i.e. clearance="1c" would set a clearance of 1 cm on all sides). The option is repeatable to set aside space on more than one side (e.g. clearance=["w1c", "s2c"] would set a clearance of 1 cm on west side and 2 cm on south side). Such space will be left untouched by the main map plotting but can be accessed by methods that plot scales, bars, text, etc.

• margins (float | str | Sequence[float | str] | None, default: None) –

  Margin space that is added between neighboring subplots (i.e., the interior margins) in addition to the automatic space added for tick marks, annotations, and labels. The margins can be specified as either:

  • a single value (for same margin on all sides). E.g. "5c".

  • a pair of values (for separate horizontal and vertical margins). E.g., ("5c", "3c").

  • a set of four values (for separate left, right, bottom, and top margins). E.g., ("1c", "2c", "3c", "4c").

  The actual gap created is always a sum of the margins for the two opposing sides (e.g., east plus west or south plus north margins) [Default is half the primary annotation font size, giving the full annotation font size as the default gap].

• sharex (bool or str) – Set subplot layout for shared x-axes. Use when all subplots in a column share a common x-range. If sharex=True, the first (i.e., top) and the last (i.e., bottom) rows will have x-annotations; use sharex="t" or sharex="b" to select only one of those two rows [both]. Append +l if annotated x-axes should have a label [none]; optionally append the label if it is the same for the entire subplot. Append +t to make space for subplot titles for each row; use +tc for top row titles only [no subplot titles].

• sharey (bool or str) –

  Set subplot layout for shared y-axes. Use when all subplots in a row share a common y-range. If sharey=True, the first (i.e., left) and the last (i.e., right) columns will have y-annotations; use sharey="l" or sharey="r" to select only one of those two columns [both]. Append +l if annotated y-axes will have a label [none]; optionally, append the label if it is the same for the entire subplot. Append +p to make all annotations axis-parallel [horizontal]; if not used you may have to set clearance to secure extra space for long horizontal annotations.

  Notes for sharex/sharey:

  • Labels and titles that depends on which row or column are specified as usual via a subplot’s own frame setting.

  • Append +w to the figsize or subsize parameter to draw horizontal and vertical lines between interior panels using selected pen [no lines].

• title (str | None, default: None) – Set the overarching heading of the entire figure [Default is no heading]. Font is determined by FONT_HEADING. Individual subplot can have titles set by sharex/sharey or frame.

• projection (str | None, default: None) – projcode[projparams/]width|scale. Select map projection.

• region (str or list) – xmin/xmax/ymin/ymax[+r][+uunit]. Specify the region of interest.

• frame (bool, str, or list) – Set map boundary frame and axes attributes.

• verbose (bool or str) – Select verbosity level [Full usage].

Examples using pygmt.Figure.subplot

Multiple colormaps

Multiple colormaps

Calculating grid gradient with custom azimuth and normalization parameters

Calculating grid gradient with custom azimuth and normalization parameters

Vertical or horizontal bars

Vertical or horizontal bars

Performing grid histogram equalization
